Testing & Handing over:
Once the installation is completed, our senior Technical Engineers will test the elevator thoroughly and hand over the lift in good working condition. We also make it a point to take the customer feedback after a week of installation, regarding the performance of the elevator.
Elevator Service:
A separate service team will attend the call backs as well as, provide regular maintenance to the elevators installed. We also provide training, for emergency maintenance services.
What is a Hydraulic Lift?
Hydraulic Lift consists of an Oil Tank, which is known as a PowerPack which will have Valves, Oil, Pump
inside oil connected through a Hose Pipe to the cylinder. Inside the Cylinder the piston will move up
and down, which is connected to the cabin by a rope. When should you choose a Hydraulic Lift? If you do not want to go for a pit, head room and machine room above the lift, then the right choice is Hydraulic. Also if your staircase is located inside the house then go for Hydraulic lift as machine will be outside the house, it is easy to access in case of
emergency.
How does a Hydraulic Lift work?
From the oil tank, oil will be pumped into the cylinder and so the piston will move up and down. The piston will be connected to the cabin and for every one foot of the piston travel, the cabin will move two feet. So we avoid the pit and extra space/headroom above the last landing.
Is pit required in a Hydraulic Lift?
If you do not wish to have a pit for your hydraulic lift, then you would go for an 8-inch step in front of the elevator. Or else you much at least go for an 8 inches pit. The reason behind this is due to the bottom of the cabin should be strong enough to carry the load.
How much power does a this Lift consume?
Power consumption will depend on the load capacity. However, hydraulic home lifts don’t consume power while coming down, as they use gravity to get down. Oil will flow back to the power pack from the cylinder while lift moves down. When the elevator is not in use, it still consumes about 24 watts per hour and so a minimum bill of Rs 200 per month would come. For a 2-4 Passenger elevator for Ground+1 floor and Ground +2 floors, you will have a 5500-watt machine.
If it’s for a Ground +3 floors then you would have a 7500 watt machine and if it is for a glass lift or for a 6 passenger lift then the machine will be 9500 watt machine.
What is the cost of a Hydraulic Home Lift?
In Qtis Hydraulic lifts we give utmost priority to the long life of the elevator and so give importance to the quality. We have Indian as well as Italian models. Total price depends on several factors like type of doors, whether we are installing the lift in civil lift shaft or a self-supported shaft.
